BASELIFT 6300 / 6310 is a worktop lift with great flexibility to be adapted for different needs.

The lift can be used separately or together with Granberg's wall cabinet lift to totally adapt the kitchen. Space is left open below the work surface for knees and legs. Installations below the work surface, (motors, water, drainage), can be concealed by telescopic cover plates that give the kitchen an attractive appearance.

The motors are continuously adjustable and move the work surface quickly and silently to the required height. The lift is equipped with a reliable safety system that guarantees safe operation with no risk of crushing.

The equipment in the work surface is selected according to the function desired. Sink unit, hob, drawers, chopping boards and other accessories can be integrated in the work surface.

Functions and Advantages

Can be equipped with drawers, hob and sink
30 cm height adjustment
Adjustable depth, 56 – 59 cm from wall
Frame in aluminium. Prepared from factory. Movable (sideward) and angle adjustable consoles.
Electronic and motor system Plug and Play
Safety strip covers the front edge under the worktop. (Installed from factory)
Brackets and screws for installation countertop are included in the delivery

Useful information

The countertops depth must be 15 mm shallower than adjoining countertops (to provide a gap for tiles and movement)
Width of the countertop = width of the lift
Sink bowls with a maximum height of 120 mm can be integrated
Electronics and motor system Plug and Play
Width of front = width of lift -4 mm
Height of front: 103 mm, fittings enclosed
Cover panels can hide installations under the worktop 2 pcs width = width of lift -10 mm, height 438 mm, thickness 12-20 mm

Standard equipment

Factory-mounted aluminium system with movable and tiltable brackets
Wall-mounted motors
Safety switch
Front (White ALU RAL 9003)
Control Button, Mini

Casework
